Appendix - Setting up Jog-Shuttle Devices
If you have any Jog-Shuttle device on your computer, you may set it up for DVD-lab PRO.
The Shuttle devices works by sending keystrokes to the application. For list of short-keys you may refer to Shortkey topic in each part of this help file or see the Summary here. DVD-lab PRO has keystrokes set such way so you can create comfortable layout on the Shuttle Devices.
In this document we will suggest a setting for Shuttle controller ShuttlePRO v2 from Contour Design. It is easy to adapt these settings for any other similar controller.
Shortkey Summary
| Function |
Keystroke |
Frequency |
In Movie |
In Menu |
In Connections |
| Previous Chapter /Object |
Page Down |
|
Select Previous Chapter |
Select Previous Object |
Select Previous Item |
| Next Chapter/Object |
Page Up |
|
Select Next Chapter |
Select Next Object |
Select Next Item |
| Insert Chapter/Link |
Space |
|
Insert Chapter point |
Display Link choices |
- |
| Remove Chapter/Link |
Shift + Del |
|
Delete selected Chapter |
Display Remove link |
- |
| Delete |
Del |
|
delete movie, audio |
delete object |
delete item |
| Zoom In |
NumPad + |
|
Zoom in |
Zoom In |
Zoom In |
| Zoom Out |
NumPad - |
|
Zoom Out |
Zoom Out |
Zoom Out |
| Connections Window |
Ctrl+Home |
|
Bring up Connection Window |
| Tool 1 |
1 |
|
- |
Arrow |
Arrow |
| Tool 2 |
2 |
|
- |
Text |
Draw links |
| Tool 3 |
3 |
|
- |
Rectangle |
Draw Button links |
| Tool 4 |
4 |
|
- |
Group Hotspot |
Menu transition |
| Tool 5 |
5 |
|
- |
3D Rotate |
Menu Button link |
| Tool 6 |
6 |
|
- |
Cardinal Shape |
Create Component |
| Tool 7 |
7 |
|
- |
Frame |
Move view |
| Tool 8 |
8 |
|
- |
Simulation |
Table |
| Tool 9 |
9 |
|
Scroll Movie Left |
- |
Move view Left |
| Tool10 |
0 |
|
Scroll Movie Right |
- |
Move View Right |
| Jog Left |
Mouse Wheel Down |
|
Scroll Movie Left |
Zoom Out |
Move View Down |
| Jog Right |
Mouse Wheel Up |
|
Scroll Movie Right |
Zoom In |
Move View Up |
| Shuttle Left 1 |
[ |
5 x /sec |
Scroll Fast 1 Left |
- |
Move View Left |
| Shuttle Left 2 |
[ |
15 x /sec |
Scroll Fast 2 Left |
- |
-||- |
| Shuttle Left 3 |
[ |
45 x /sec |
Scroll Fast 3 Left |
- |
-||- |
| Shuttle Left 4 |
; |
15 x /sec |
Scroll Faster Left |
- |
-||- |
| Shuttle Left 5 |
; |
30 x /sec |
Scroll Faster Left |
- |
-||- |
| Shuttle Left 6 |
; |
45 x /sec |
Scroll Faster Left |
- |
-||- |
| Shuttle Left 7 |
9 |
30 x /sec |
Scroll Fastest Left |
- |
-||- |
| Shuttle Right 1 |
] |
5 x /sec |
Scroll Fast 1 Right |
- |
Move View Right |
| Shuttle Right 2 |
] |
15 x /sec |
Scroll Fast 2 Right |
- |
-||- |
| Shuttle Right 3 |
] |
45 x /sec |
Scroll Fast 3 Right |
- |
-||- |
| Shuttle Right 4 |
' |
15 x /sec |
Scroll Faster Right |
- |
-||- |
| Shuttle Right 5 |
' |
30 x /sec |
Scroll Faster Right |
- |
-||- |
| Shuttle Right 6 |
' |
45 x /sec |
Scroll Faster Right |
- |
-||- |
| Shuttle Right 7 |
0 |
30 x /sec |
Scroll Fastest Right |
- |
-||- |
A recommended ShuttlePRO layout*
| |
| Tool 2 |
| |
| Tool 1 |
| |
| Zoom Out |
| |
| Zoom In |
| |
|
Previous Chapter/Object
|
| |
| Left side Shuttle Positions |
| 1 |
Scroll Fast 1 |
| 2 |
Scroll Fast 2 |
| 3 |
Scroll Fast 3 |
| 4 |
Scroll Faster |
| 5 |
Scroll Faster |
| 6 |
Scroll Faster |
| 7 |
Scroll Faster |
|
| |
| Copy |
| |
| Paste |
|
|
Connections Window
|
 |
|
| |
|
Tool 3
|
| |
|
Tool 7
|
| |
|
Tool 8
|
| |
|
Delete
|
| |
| Next Chapter/Object |
| |
|
Right side Shuttle Positions
|
|
Scroll Fast 1
|
1
|
|
Scroll Fast 2
|
2
|
|
Scroll Fast 3
|
3
|
|
Scroll Faster
|
4
|
|
Scroll Faster
|
5
|
|
Scroll Faster
|
6
|
|
Scroll Faster
|
7
|
|
| |
|
Insert Chapterpoint/Link
|
| |
|
Delete Chapter/Link
|
|
*ShuttlePRO (c) and (tm) of Contour Design.
